956 Series Flat Top Modular Belt
50.8 mm pitch 956 series flat top modular belt from Veybelt - food-grade material options, custom widths, fast quotation.
Product Description
Product Details
Overview
Most of what this belt carries is packaged: bottles, cartons, trays. The 956 Series Flat Top Modular Belt has a completely closed, smooth flat top surface on a 50.8 mm pitch, injection molded from PP / PE and brick-layed with hinge rods. It runs straight, drives positively on sprockets and can be built to almost any width and length.
Technical Specifications
| Series | 956 |
| Product Type | 956 Series Flat Top Modular Belt |
| Pitch | 50.8 mm |
| Thickness | 16 mm |
| Open Area | 0% |
| Belt Strength | 27,000 N/m (PP) |
| Material | PP / PE |
| Color | White, Natural, Blue, Grey |
| Belt Width | Custom widths available on request |
| Optional Attachments | Flights (cleats) and side guards available - see accessories |
| Food Contact | FDA / EU compliant food-grade material available |
Applications
- Bottling and beverage filling lines
- Packaged food conveying
- Cartons, trays and packaged goods handling
- General factory transport lines
Features & Advantages
- Tight dimensional tolerance from purpose-developed injection molds
- No slippage, no mistracking: the sprocket drive is positive
- Repair by swapping modules, not replacing the whole belt
- Food-grade materials meeting FDA / EU food-contact requirements available
Shipping & Usage
Good to Know
FAQ
Frequently Asked Questions
Is the 956 Series Flat Top Modular Belt available in food-grade material?
Yes. Standard modules are molded from PP/PE (POM where applicable) resins that comply with FDA and EU food-contact regulations. We can include material compliance certificates with your order.
What are the MOQ and lead time?
MOQ is negotiable for standard items, so small trial orders are fine. Production usually takes 10-20 days depending on quantity and color; in-stock standard items ship faster.
Which sprockets should I pair with this belt?
The matching 956 series POM sprockets. They come in several teeth counts and bore sizes; send us your shaft size and we'll recommend the exact one.
