936 Series Flush Grid Modular Belt
38.1 mm pitch 936 series flush grid modular belt from Veybelt - food-grade material options, custom widths, fast quotation.
Product Description
Product Details
Overview
If product sits wet on the belt after washdown, an open surface is usually the fix. The 936 Series Flush Grid Modular Belt is a 38.1 mm pitch belt with an open-grid surface (25% open area) that lets water drain and air circulate. It's injection molded from PP and assembled brick-layed with hinge rods: straight running, positive sprocket drive, and buildable to almost any width and length.
Technical Specifications
| Series | 936 |
| Product Type | 936 Series Flush Grid Modular Belt |
| Pitch | 38.1 mm |
| Belt Strength | 33,000 N/m (PP) |
| Thickness | 18 mm |
| Open Area | 25% |
| Material | PP |
| Color | Beige |
| Belt Width | Custom widths available on request |
| Optional Attachments | Flights (cleats) and side guards available - see accessories |
| Food Contact | FDA / EU compliant food-grade material available |
Applications
- Washdown food processing lines
- Cooling and draining sections
- Fruit and vegetable washing lines
- Seafood and meat processing
Features & Advantages
- Produced on dedicated injection molding lines with full dimensional inspection
- Molded POM sprockets give accurate, slip-free drive
- Module-level repairs keep replacement cost and downtime low
- Food-grade material options for hygienic lines (FDA / EU compliant)
Shipping & Usage
Good to Know
FAQ
Frequently Asked Questions
Is the 936 Series Flush Grid Modular Belt available in food-grade material?
Yes. Standard modules are molded from PP/PE (POM where applicable) resins that comply with FDA and EU food-contact regulations. We can include material compliance certificates with your order.
What are the MOQ and lead time?
MOQ is negotiable for standard items, so small trial orders are fine. Production usually takes 10-20 days depending on quantity and color; in-stock standard items ship faster.
Which sprockets should I pair with this belt?
The matching 936 series POM sprockets. They come in several teeth counts and bore sizes; send us your shaft size and we'll recommend the exact one.
