Product Story

900 Series Flush Grid Modular Belt

Name: 900 Series Flush Grid Modular Belt
Brand: Veybelt
SKU: VL-900-FG

27.2 mm pitch 900 series flush grid modular belt from Veybelt - food-grade material options, custom widths, fast quotation.

Washdown food processing linesCooling and draining sectionsFruit and vegetable washing linesSeafood and meat processing

$NaN

SKUVL-900-FG

Lead Time10-20 days

Product Description

Overview

Poultry and food processing lines running 27.2 mm pitch belts usually spec a flush grid surface so wash water drains through instead of pooling on the product. The 900 Series Flush Grid Modular Belt gives 31.7% open area for drainage and airflow. Modules are injection molded from PP / POM / PE and connected with hinge rods in a brick-lay pattern, which keeps lateral strength high and lets you lengthen or shorten the belt row by row.

Technical Specifications

Series	900
Product Type	900 Series Flush Grid Modular Belt
Pitch	27.2 mm
Belt Strength	17,500 N/m (PP) / 40,300 N/m (POM)
Thickness	9 mm
Open Area	31.7%
Material	PP / POM / PE
Color	Natural, Grey, Blue, Brown
Belt Width	Custom widths available on request
Optional Attachments	Flights (cleats) and side guards available - see accessories
Food Contact	FDA / EU compliant food-grade material available

Applications

Washdown food processing lines
Cooling and draining sections
Fruit and vegetable washing lines
Seafood and meat processing

Features & Advantages

Consistent module quality from dedicated, purpose-built injection tooling.
Hinge-driven engagement with matching POM sprockets keeps the belt from slipping under load.
Module-level repair. Replace the damaged rows, not the belt.
PP/PE food-contact grades (FDA and EU compliant) available for processing lines.

物流与说明

运输承诺、使用说明和补充信息。

Ships from a cross-border fulfillment center

Third-party lab tested and quality checked

Localized post-purchase support included

常见问题

FAQ 问答列表，减少售前阻力。

Is the 900 Series Flush Grid Modular Belt available in food-grade material?

Yes. Molded from PP/PE resins (POM where applicable) that comply with FDA and EU food-contact regulations. Material compliance certificates can be provided with your order.

What are the MOQ and lead time?

Small trial orders are welcome; MOQ is negotiable on standard items. Lead time is typically 10-20 days in production, depending on quantity and color. In-stock standard items ship faster.

Which sprockets should I pair with this belt?

The matching 900 series POM sprockets, in multiple teeth counts and bore sizes. Give us your shaft size and we'll spec the exact one.
