Product Story
7300 Series Flush Grid Modular Belt
7300 series flush grid modular belt from Veybelt - food-grade material options, custom widths, fast quotation.
Product Description
Product Details
Overview
Cooling and draining sections need air and water to move through the belt, not sit on the product. The 7300 Series Flush Grid Modular Belt gives you that open-grid surface in PP / PE: injection molded modules, brick-layed with hinge rods, so the belt runs straight and drives positively on sprockets. Custom widths are available on request.
Technical Specifications
| Series | 7300 |
| Product Type | 7300 Series Flush Grid Modular Belt |
| Material | PP / PE |
| Color | White, Natural, Blue |
| Belt Width | Custom widths available on request |
| Optional Attachments | Flights (cleats) and side guards available - see accessories |
| Food Contact | FDA / EU compliant food-grade material available |
Applications
- Washdown food processing lines
- Cooling and draining sections
- Fruit and vegetable washing lines
- Seafood and meat processing
Features & Advantages
- Molded on dedicated injection lines with full dimensional inspection.
- Accurate, slip-free drive on molded POM sprockets.
- Module-level maintenance. A damaged row is a cheap swap, not a new belt.
- FDA / EU compliant food-grade material options for hygienic lines.
Shipping & Usage
Good to Know
FAQ
Frequently Asked Questions
Is the 7300 Series Flush Grid Modular Belt available in food-grade material?
Yes. It's molded from PP/PE (and POM where applicable) resins compliant with FDA and EU food-contact regulations, and material compliance certificates can be provided with your order.
What are the MOQ and lead time?
MOQ is negotiable for standard items, small trial orders included. Production usually takes 10-20 days depending on quantity and color; in-stock standard items ship faster.
Which sprockets should I pair with this belt?
The matching 7300 series POM sprockets, in multiple teeth counts and bore sizes. Tell us your shaft size and we'll recommend the right one.
