5935 Series Flush Grid Modular Belt
19.05 mm pitch 5935 series flush grid modular belt from Veybelt - food-grade material options, custom widths, fast quotation.
Product Description
Product Details
Overview
The 5935 Series Flush Grid Modular Belt is the open-surface version of the 5935 line: a 19.05 mm pitch plastic modular belt with an open grid for drainage and airflow. Modules come in PP / POM / PE, connected with hinge rods in a brick-lay pattern for high lateral strength. Need the belt longer or shorter? You just add or remove rows.
Technical Specifications
| Series | 5935 |
| Product Type | 5935 Series Flush Grid Modular Belt |
| Pitch | 19.05 mm |
| Belt Strength | 11,800 N/m (PP) / 20,700 N/m (POM) |
| Thickness | 8.3 mm |
| Open Area | 26.9% |
| Material | PP / POM / PE |
| Color | Natural, Brown, Blue |
| Belt Width | Custom widths available on request |
| Optional Attachments | Flights (cleats) and side guards available - see accessories |
| Food Contact | FDA / EU compliant food-grade material available |
Applications
- Washdown food processing lines
- Cooling and draining sections
- Fruit and vegetable washing lines
- Seafood and meat processing
Features & Advantages
- Purpose-built injection tooling keeps module quality consistent from batch to batch.
- Hinge-driven engagement with matching POM sprockets. No slippage.
- Repair by module: replace the damaged pieces and keep the rest of the belt in service.
- Food-grade PP/PE compliant with FDA and EU food-contact regulations available.
Shipping & Usage
Good to Know
FAQ
Frequently Asked Questions
Is the 5935 Series Flush Grid Modular Belt available in food-grade material?
Yes. The belt is molded from PP/PE (and POM where applicable) resins compliant with FDA and EU food-contact regulations. Compliance certificates can go out with your order on request.
What are the MOQ and lead time?
MOQ is negotiable for standard items and we're happy to run small trial orders. Typical production lead time is 10-20 days depending on quantity and color; in-stock standard items ship faster.
Which sprockets should I pair with this belt?
Use the matching 5935 series POM sprockets, available in multiple teeth counts and bore sizes. Tell us your shaft size and we'll recommend the exact one.
